NERI MARCHESINI - Labelling Machine - BL400

NERI MARCHESINI LABELLING MACHINE, MODEL BL400

Year of construction: 2008

Automatic carton linear labelling machine. The balcony construction makes the clearance procedures extremely easy, the positive transport system of cartons makes the machine completely fail-safe. The machine is divided in three areas: operative, mechanical and electrical.

MACHINE FEATURES

• labelling machine balcony construction in stainless steel
• electrical cabinet on machine board
• easy access to electrical and mechanical parts from behind
• positive transport of cartons with toothed belts
• tamper evident seals application (VTE and TE)
• automatic label changing system with set-up by keyboard and possibility to memorize different label sizes
• self-diagnosis on 6” colour touch display on swiveling arm

PRODUCTION CHARACTERISTICS

• Maximum rate: 400 pcs/min
• Label speed: 0 ÷ 50 m/min
• Maximum reel diameter: 400 mm

Minimum load control at the inlet/Maximum load control at the outlet

• Carton width (A): 20 ÷ 180 mm
• Carton height (B): 15 ÷ 120 mm
• Carton length (C): 70 ÷ 200 mm

• Vignette height: 20 ÷ 60 mm
• Vignette length: 15 ÷ 80 mm

ENERGY

• Standard electric power supply: 380 - 220 V-50 Hz
• Installed power: 2 kW
• Compressed air consumption: 20 Nl/min
• Compressed air pressure: 6 bar
